Specifications
Frequency Response
| On Axis @ 0° ±3dB | 90-23,000Hz |
|---|---|
| On Axis @ 0° ±1 1/2dB | 100-20,000Hz |
| Off Axis @ 30° ±1 1/2dB | 100-10,000Hz |
| LF Cutoff -10dB | 70Hz |
Sensitivity
| Anechoic Chamber | 87dB |
|---|---|
| Listening Room | 89dB |
Impedance
| Nominal | 8 Ohms |
|---|---|
| Minimum | 6 Ohms |
Input Power
| Recommended | 10 - 80 Watts |
|---|---|
| Program | 60 Watts |
Acoustic Design
| Tweeter (Nominal) | 1" (25mm) Titanium Dome with Ferrofluid |
|---|---|
| Woofer (Nominal) | 2 x4" (102mm) Clay/Ceramic reinforced Polypropylene Cone Rubber Surround |
| Crossover | 2300Hz LR4 |
| Internal Volume | 0.10 cu ft (2.9 L) |
| Design Type | Passive Radiator |
Dimensions / Weights / Finish
| Size (W x H x D) | 27 1/2 x5 1/2 x3 1/4" * 700 x140 x82mm |
|---|---|
| Net Weight | Net - 9.33lb (4.24kg)/each Shipping - 14.9lb (6.77kg)/each |
| Finish | High Gloss Black |
| Notes | * Non-metric measurements are approximate. All specifications are subject to change without notice. |
