Imagine XA Atmos Speaker

Only 0 left!
ARCHIVE
THIS PRODUCT IS NO LONGER FOR SALE

Dolby Atmos® Propel Your Sound

The Imagine XA is the latest addition to the Imagine X series, and the first PSB speaker to be Dolby Atmos® certified. Used as the elevation or height speaker in an affordable Dolby Atmos surround system, the Imagine XA creates an enthralling layer of sound – from above. The Imagine XA enables you to get the best and latest Dolby format, and has been used by Dolby themselves to flaunt their new Dolby Atmos® Multi-channel Surround specification.

Advanced vertically-firing driver array

Advanced vertically-firing driver array

Working with Dolby and using advanced acoustic research, PSB crafted the Imagine XA with custom-designed vertically firing drivers that accurately reflect sound off of your ceiling. The Imagine XA’s frequency response and directivity pattern have been specifically engineered to meet Dolby’s Atmos specifications so you can hear the lifelike detail of your favourite films as if you were truly there.

Add Dolby Atmos® to your existing home theatre system

The Imagine XA is purpose-built to fit on top of PSB’s Imagine X Series floor-standing and bookshelf speakers, creating a 5.1.2 to 7.1.4 or beyond Dolby Atmos enabled system from your existing home theatre setup. When combined with either the Imagine X2T or X1T, the Imagine XA can harness the power of the tower speakers, ultimately creating a richer listening experience.

Add Dolby Atmos® to your existing home theatre system
Flexible to install

Flexible to install

Unobtrusive in the home, the Imagine XA is small enough to sit atop your existing front or rear speakers, whether they are bookshelf or towers. It can also easily be mounted to a wall with the included brackets. Elevating the cinematic experience without the need to install in-ceiling speakers is what the XA is all about.

Seamless Integration

The Imagine XA Atmos speaker features custom-designed drivers that inherit PSB’s flagship technologies. It includes a 1-inch titanium dome tweeter with ferrofluid and neodymium magnet structure, a 4-inch clay/ceramic reinforced injection-molded polypropylene cone woofer. Designed for seamless integration with other Imagine X Series speakers, the Imagine XA also offers five-way gold-plated binding posts for versatile connectivity.

Seamless Integration

Specifications

Frequency Response

On Axis @ 0° ±3dB 100 - 23,000Hz
LF Cutoff -10dB 60Hz

Sensitivity

Anechoic Chamber 85dB
Listening Room 87dB

Impedance

Nominal 8 Ohms
Minimum 4 Ohms

Input Power

Recommended 10 - 80 Watts

Acoustic Design

Tweeter (Nominal) 1" (25mm) Titanium Dome with Ferrofluid Neodymium Magnet
Woofer (Nominal) 4" (102mm) Clay/Ceramic reinforced Injection Moulded Polypropylene Cone Rubber Surround Turbo Magnet
Crossover 2,000Hz, B3
Design Type Sealed

Dimensions / Weights / Finish

Size (W x H x D) 6 1/2 x10 1/2 x6 3/4"* 168 x173 x265mm
Weight Net - 6.5lb (2.9kg)/each Shipping - 15.6lb (7.1kg)/each
Notes * Non-metric measurements are approximate. All specifications are subject to change without notice.
