Attractive and compact

Ideal for smaller rooms or in combination with a powered subwoofer for a compact full-range system, Imagine XB bookshelf speakers are proof that good things do come in small packages. Used as the foundation of a great starter system or in combination with a more powerful receiver and subwoofer, the Imagine XBs will bring you excellent hifi sound, and an affordable price.

Customer Reviews

Write Your Own Review
You're reviewing:Imagine XB – Bookshelf
Your Rating

Specifications

More Information
Price $849.00
wireless_speaker No
Specifications

Frequency Response

On Axis @ 0° ±3dB 50-20,000Hz
On Axis @ 0°±1 1/2dB 70-20,000Hz
Off Axis @ 30°±1 1/2dB 70-10,000Hz
LF Cutoff -10dB 50Hz

Sensitivity

Anechoic Chamber 87dB
Listening Room

89dB

Impedance

Nominal 8 Ohms
Minimum 4 Ohms

Input Power

Recommended 20 - 150 Watts
Program 150 Watts

Acoustic Design

Tweeter (Nominal)

1” (25mm) Titanium Dome with Ferrofluid

Neodymium Magnet

Woofer (Nominal)

5 1/4” (133mm) Injection Moulded Clay/Ceramic reinforced

Polypropylene Cone

Rubber Surround / Dual Magnet

Crossover

1,800Hz, LR4

Internal Volume

0.32 cu ft (9.1L)

Design Type

Bass Reflex Rear Port

Dimensions / Weights / Finish

Size (W x H x D)

6 3/4 x 12 x 10 3/4” *

170 x 302 x 271mm

Weight

Net - 12.3lb (5.6kg)/each

Shipping - 27.7lb (12.6kg)/pair

Finish Black Ash
Notes

* Non-metric measurements are approximate.

All specifications are subject to change without notice.
